Zoom H3-VR Handy Recorder

• 4 built-in microphones
• 360 degree audio recording
• Ideal for movies, live-streaming, gaming and more
• 6-axis motion sensor
• Integrated Limiter and Low cut filter
• LCD Display
• SD card not included

Zoom H3-VR Handy Recorder

Zoom The H3-VR Handy Recorder is the ideal choice if you need to record sound effects for movies, live-streaming, games and more. The 4 built-in microphones, arranged in an Ambisonic array provide room feel. This effect, combined with images for movies and games, gives the audience some amazing experiences.

Recording Media:

Cards compatible with microSD/microSDHC/microSDXC specifications

(Class 4 or higher)

Recording formats:

Ambisonics  A,  Ambisonics  B  (FuMa/AmbiX)

WAV  4ch  poly  (supports  BWF  and  iXML):  44.1  kHz/16-bit,  44.1  kHz/24-bit,   48  kHz/16-bit,  48  kHz/24-bit,  96  kHz/16-bit,  96  kHz/24-bit

Stereo

WAV  stereo  (supports  BWF  and  iXML):  44.1  kHz/16-bit,  44.1  kHz/24-bit,   48kHz/16-bit,  48  kHz/24-bit,  96  kHz/16-bit,  96  kHz/24-bit

Binaural

WAV  stereo  (supports  BWF  and  iXML):  44.1  kHz/16-bit,  44.1  kHz/24-bit,   48kHz/16-bit,  48  kHz/24-bit

Display:

1.25" monochrome LCD (96×64)

Motion sensor:

6 axes (3-axis gyro, 3-axis acceleration)

Built-in Ambisonic mic:

4 matched unidirectional condenser mics

Maximum sound pressure input: 120 dB SPL

Mic gain: +18 - +48 dB

LINE OUT:

Connector: 3.5 mm stereo mini

Maximum output level: -10 dBu (1 kHz, 10 k load)

PHONE OUT:

Connector: 3.5 mm stereo mini

Maximum output level: 20 mW + 20 mW (into 32 load)

USB:

Connector: microUSB

Mass storage operation

- USB 2.0 High Speed

Audio interface operation

- 2 in/2 out (stereo/binaural input), USB 2.0 Full Speed

- 44.1 kHz/16-bit, 48 kHz/16-bit

- 4 in/2 out ( Ambisonics A/FuMa/AmbiX input), USB 2.0 High Speed

- 44.1 kHz/24-bit, 48 kHz/24-bit

Power:

2 AA batteries (alkaline, rechargeable NiMH or lithium)

AC adapter (ZOOM AD-17): DC 5V/1A (supports USB bus power)

Estimated continuous recording time using batteries:

48 kHz/24-bit, FuMa Rec Mode

- Alkaline batteries: about 11.5 hours

- NiMH batteries (1900 mAh): about 11.5 hours

- Lithium batteries: about 24 hours

- The above values are approximate.

- Continuous battery operation times were determined using in-house testing methods. They will vary greatly according to use conditions.

External dimensions:

76 mm (W) × 78 mm (D) × 123 mm (H)

Weight (main unit only):

120 g
