Electro-Voice ZX1-Sub Passive Subwoofer (400W, 8 Ohm)

Electro-Voice ZX1-Sub is a passive subwoofer with 12" bass unit that delivers 800 Watt Program Power (1.200 Watt Peak)

Although the compact ZX1 Subwoofer from EV does not take up much space in the landscape, it delivers a nice sound pressure level of 127 dB Max. SPL.

The ZX1SUB can be used for a wide range of applications from bar, café and restaurant installations to mobile discos and bands.

Electro-Voice

ZX1-Sub
The new ZX1-Sub is optimized for performance with a variety of EV loudspeakers, including ZX1, EVID, and EVU models, and will add a deep low-frequency punch that you can feel as well as hear.
An ideal choice to complete a wide range of smaller fixed installations or live sound systems.

Input Connections	NL4 style (2)
Nominal Impedance	8
Frequency Response (-3 dB)	53 - 125 Hz
Frequency Response (-10 dB)	42 - 200 Hz
Sensitivity 1W/1m	94 dB
Max. SPL/ 1m (calc)	127 dB
System Power Handling (Contiuous/Program/Peak)	400 / 800 / 1600 (12'') Woofer
Enclosed Material	9-ply 15 mm plywood, inetrnally braced with textured paint     2
Grill	16 GA steel with black powder coat
Height	400 mm (15.75")
Width	444.5 mm (17.5")
Depth	457.2 mm (18")
Shipping Weight	25.4 kg (56 lbs)
Shipping Weight	39.3 kg (86.64 lbs)
